The Marantz AV7706 pre-amplifier features 8K HDMI passthrough, 3D audio formats, audiophile-quality music playback, multi-room HEOS® Built-in technology, and voice control.
CLICK HERE TO VIEW OWNERS MANUAL
Your music with Marantz
Its high-resolution preamplifier uses custom-curated Marantz HDAM technology for the purest sound in audio.
Breathtakingly Natural 3D Audio
Movie and TV sound moves around you in space, emulating the finest movie theaters and the real world.
A Wealth of Channels
From high-resolution stereo to 11.2 channel surround sound, experience pure Marantz audio through any configuration you need.
Carefully Tuned for Pure Enjoyment
No matter how you listen or what you watch, the AV7706 is carefully tuned to deliver the most enjoyable music and movie experiences you can imagine.
Advanced 11.2 channel pre-amplifier
Experience a versatile home theater setup with the new Marantz AV7706 processor/pre-amplifier. Featuring 11.2 channel XLR and RCA pre-outs, the AV7706 is built with masterful-quality external power amplification for the most demanding active speakers. Enjoy the audiophile sound you expect from Marantz combined with the latest video and audio decoding, as well as voice control with your favorite voice assistants.
Sophisticated engineering
With 11.2 channel pre-outs on both conventional RCA sockets and balanced XLRs, the AV7706 is designed to work alongside high-quality external power amplifiers like the Marantz MM8077, MM7055, and MM7025.
Advanced 8K HDMI connectivity with eARC support
The new Marantz AV7706 includes 8 HDMI inputs and 3 outputs for all your favorite sources. One dedicated 8K input supports 8K/60Hz or 4K/120Hz pass-through capability, 4:4:4 Pure Color sub-sampling, Dolby Vision, HLG, HDR10, 21:9 video, 3D, and BT.2020 pass-through while the latest HDCP 2.3 copy protection standard is supported on all HDMI inputs.
Full 3D audio support
Immerse yourself in multi-dimensional audio with the latest surround formats, including Dolby Atmos®, Dolby Atmos Height Virtualization Technology, DTS:X®, DTS Virtual:X™, IMAX® Enhanced, and Auro-3D®.
Marantz HDAM and current feedback topology
The AV7706 features exclusive Marantz Hyper Dynamic Amplifier Module (HDAM) technology that provide ultra-fast slew rate, true wideband performance, and maximum dynamic range for optimum sound quality.
The next chapter in movie entertainment
The new AV7706 offers the highest-quality, crystal-clear viewing experience. Enjoy your movies with 8K/60Hz pass-through or upscaling, as well the latest in HDMI technology like Dynamic HDR and Quick Media Switching (QMS), which is used in movies to eliminate video delay.
| General Features | |
| Bluetooth | Built-in |
| Apple AirPlay | AirPlay 2 |
| Alexa-compatible | Yes |
| Google Assistant-compatible | Yes |
| Chromecast built-in | No |
| DTS Play-Fi | No |
| App Remote Control | Yes |
| Auto Speaker Calibration | Audyssey MultEQ XT32 |
| Multi-room Audio/Video | |
| Preamp Multi-room Audio Output | Yes |
| Multi-room HDMI Output | Yes |
| Total Number of Zones | 3 |
| Playback from Digital Audio Inputs | Yes |
| Playback from Streaming Sources | Yes |
| Surround Processing | |
| Dolby Digital | DD, TrueHD, DD+ EX |
| Dolby Atmos | Yes |
| Dolby Atmos Height Virtualization | Yes |
| DTS | DTS, HD, HDMA, ES, Neo6, 96/24 |
| DTS:X | Yes |
| DTS Virtual:X | Yes |
| Inputs & Outputs | |
| Phono Input | 1 |
| Audio-Video Inputs | 8 |
| Audio-only Inputs | 2 |
| RCA Analog Stereo Inputs | 6 |
| XLR Analog Stereo Inputs | None |
| Component Video Inputs | 3 |
| Component Video Monitor Outputs | 1 |
| Optical Digital Inputs | 2 |
| Coaxial Digital Inputs | 2 |
| XLR Digital Inputs | None |
| Optical Digital Outputs | None |
| Coaxial Digital Outputs | None |
| XLR Digital Outputs | None |
| Number of HDMI Inputs | 8 |
| HDMI Monitor Outputs | 3 |
| Subwoofer Outputs | 2 |
| Discrete Subwoofer Outputs | Yes |
| Multi-Channel Analog Input | Yes |
| Multi-channel Preamp Output | 11.2ch, Zone 2/3 |
| XLR Analog Preamp Outputs | 13 |
| Ethernet Port | Yes |
| USB Connections | Yes |
| Removable Power Cord | IEC 2-prong |
| Supports Wireless Rear Speakers | No |
| HDMI Features | |
| HDMI Version | 2.1 |
| VRR (Variable Refresh Rate) | Yes |
| ALLM (Auto Low Latency Mode) | Yes |
| 4K/120Hz-Capable Inputs | 1 |
| Audio Return Channel | eARC supported |
| Video Upscaling | To 4K |
| HDR (High Dynamic Range) Support | |
| HDR10 | Yes |
| HDR10+ | Yes |
| HLG | Yes |
| Dolby Vision | Yes |
| Other Specs | |
| Multibrand Remote Control | Yes |
| Learning Remote | No |
| Width (inches) | 17.375 |
| Height (inches) | 7.3125 |
| Depth (inches) | 16.9375 |
| Weight (pounds) | 22.9 |
Buying a Marantz Factory Refurbished product is a great way to get "as-new" products at a considerable savings. Every product has been thoroughly tested, repaired (if necessary), cleaned and otherwise renewed to original condition. Next it's repackaged with original accessories included. When you consider that a factory-renewed Marantz product undergoes such close scrutiny for defects and workmanship, you might actually be buying something that is in many ways better than new. And for your piece of mind and protection, your purchase is covered by a full 1 year parts and labor warranty valid at any authorized Marantz repair center (you can look-up locations online here or call 800-654-6633)
Marantz, like all electronics manufactures, receives products returned for various reasons. In 2023 consumers returned 23 billion dollars in electronics globally, of which less than 5% were found to be defective! Once a product has been opened, it must be resold as refurbished or open box and cannot be resold as new again. The history and reason why a product was returned is not provided to us, thus we cannot provide any additional details regarding its past. All products are processed by Marantz certified technicians, where they are fully tested, repaired (only if necessary), and retested again to ensure the highest quality control. Each unit must pass a complete battery of test before it can be titled a "Marantz Factory Refurbished" product.
Most (not all) units are cosmetically in Mint Condition (graded a 9 or higher on a scale of 1-10). Very minor signs of wear (light surface scuffs or minor scratches) may be present, although most units show little or no signs of any usage. We DO NOT sell products that are cosmetically damaged (cracked displays, broken knobs, heavy scratches, or physically abused) unless noted in the description. Unfortunately, we cannot provide actual photos of each unit or pick the best one for anyone, as they are all randomly chosen from our factory sealed boxes.
