The 100IWLCR5 loudspeakers which are dedicated to home audio can be highlighted for their acoustics performances and compact design. These products are aimed at small to medium sized rooms and for three types of use: distributed systems (hallways, living rooms…), stereo systems (bedrooms, kitchens…) and Home Cinema systems (in dedicated rooms or living rooms).
• 5 1/8” (13 cm) Polyglass cone. Natural midrange without colouration and rich bass.
• 360° tweeter rotation and 20° inclination.
• 1” (25 mm) aluminum inverted dome tweeter.
• Adjustable tweeter level and mid-range level. Improved sound adjustment according to the acoustic environment.
This in-wall loudspeaker has a new aluminum inverted dome adjustable tweeter, more compact, improving the sound dispersion. It is also equipped with a new Polyglass cone (51/8” – 13 cm). This LCR (Left, Centre, Right) loudspeaker can be used horizontally, as a center channel for a Home Cinema systems. It has a three position switch which allows choosing the left, center or right channels to adjust the levels according to the acoustic environment.
This product can be installed everywhere thanks to a compact design with the speaker driver’s basket and chassis being redesigned as one only piece, frameless square and circular front grilles. Let yourself be surprised by the technology behind this product, an efficient design and ideal features for an easy use at this price.
100 IW6 and 100IWLCR5 have adjustable tweeter level offer three position switch (-3dB, 0 dB, +3 dB) to adjust the treble according to the acoustic environment (reverberation on windows or on tiles for example). Two loudspeakers can be connected to the same amplifier.
Installation is an important criterion: the three mounting brackets with optimized grips ensure a quick and easy installation. This system prevents screws from falling out when dismantling the product. The installation time is kept to a minimum. The 100 Series products have a shallow mounting depth which makes the installation much easier.
Tropicalisation is used on Polyglass membranes to allow an installation in humid environments, such as bathrooms for example.
| Drivers | 2 x 5" (13cm) Polyglass Midbass. |
| 1" (25mm) AI inverted dome Tweeter | |
| Sensitivity (2.83V/1m) | 90.5dB |
| Frequency response (+/-3dB) | 55Hz-23kHz |
| Low frequency point (-6dB) | 43Hz |
| Nominal impedance | 8 Ώ |
| Minimal impedance | 3.8 Ώ |
| Recommended amplifier power | 25-120W |
| External dimensions (Ø/Depth) | 17-21/64" x 6-13/16" x 3-25/64"(440 x 173 x 86mm) |
| Cut-Out diameter | 16-11/32" x 5-25/32" (415 x 147mm) |
| Depth from wall | 3-17/64" (88mm) |
| Net weight (with front grille) | 3.89 lbs (2.9kg) |
